- Table of Contents:
- Go to Asix USB 3.0 to Gigabit Ethernet
- Go to Asix USB 2.0 to Gigabit Ethernet
- Go to Asix USB 2.0 to Fast Ethernet
Usb2lan Network App
Jun 23, 2017 Method 3: Remove and Reinstall Your Network Adapter. First of all take a note of the name of your network adapter if it is listed in the Device Manager. To see if it is listed, Hold the Windows Key and Press R. Type hdwwiz.cpl and click OK. Get to the Network Adapters tab and note down the name.
USB 3.0 to Gigabit Ethernet
Usb2lan Network Provider
This solution targets microcontrollers that already have a USB host interface embedded. In this case, an internal or external USB-to-LAN controller can be used to connect these devices to the Ethernet.
The so-called USB-to-LAN approach converts an USB 2.0/3.0 signal to the Fast Ethernet/Gigabit Ethernet interface through an USB-to-LAN controller used in the cradle or docking station for the mobile devices. Because the USB 2.0/3.0 uses a compact four/nine-pin connector, this solution reduces many of the pin-out connections between the cradle/docking station and the mobile devices. Another, more flexible way is to use an external USB-to-LAN dongle to connect the mobile devices to the network if the microcontroller within the devices has a built-in USB host interface. This will leverage the SuperSpeed and serial bus characteristic of USB 3.0, to improve the performance of the devices.
- 802.11n Wifi wireless adapter Windows 7 Windows 8 Windows 10Android, Linux, Mac OS: Link: https://www.mediatek.com/products/broadbandWifi/mt7601uhttps:/.
- The USB LAN Adapter can be used when users want to access broadband internet connections for research purposes on the web. It has one port and it follows a protocol of IEEE 802.3 and IEEE 802.3U. This device has an advanced encryption like the WPA, WEP and WPA2.
This solution is suitable for computer peripherals, handheld devices, home electronics and appliances, streaming media, broadband media, and other consumer electronics such as for Notebooks/MIDs/UMPCs/Tablet PCs, ultrabooks, USB to Ethernet dongles, cradles/port replicators/docking stations, game consoles, digital-home appliances, and any embedded system using a standard USB port.
| Part No. | USB Speed | USB Hub | Ethernet MAC/Phy(mbps) | MAC Interface | Crossover Detection and Correction | IP/TCP/UDP | Wake-on-LAN | Serial Interface | Temp Range | Package | Purchase |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AX88179QF | Super (3.0) | - | 10/100/1000 | - | V | V | V | - | 0 ~ +70C | QFN-68 |
USB 2.0 to Gigabit Ethernet
Usb2lan Network Connection
| Part No. | USB Speed | USB Hub | Ethernet MAC/Phy(mbps) | MAC Interface | Crossover Detection and Correction | IP/TCP/UDP | Wake-on-LAN | Serial Interface | Temp Range | Package | Purchase |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AX88178AQF | High (2.0) | - | 10/100/1000 | - | V | V | V | - | 0 ~ +70C | QFN-68 | |
| AX88178LF | High (2.0) | - | 10/100/1000 (MAC only) | MII/GMII/RGMII | - | - | V | - | 0 ~ +70C | LQFP-128 |
USB 2.0 to Fast Ethernet
| Part No. | USB Speed | USB Hub | Ethernet MAC/Phy(mbps) | MAC Interface | Crossover Detection and Correction | IP/TCP/UDP | Wake-on-LAN | Serial Interface | Temp Range | Package | Purchase |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AX88772CLF | High (2.0) | - | 10/100 | RMII/Rev-RMII (Optional) | V | V | V | - | 0 ~ +70C | LQFP-64 | |
| AX88772BLF | High (2.0) | - | 10/100 | RMII/Rev-RMII (Optional) | V | V | V | - | 0 ~ +70C | LQFP-64 | |
| AX88772BLI | High (2.0) | - | 10/100 | RMII/Rev-RMII (Optional) | V | V | V | - | -40 ~ +85C | LQFP-64 | |
| AX88772ALF | High (2.0) | - | 10/100 | - | V | - | V | I2C, SPI UART | 0 ~ +70C | LQFP-64 | |
| AX88172ATF | High (2.0) | - | 10/100 | (Rev-)MII/REV-RMII | V | - | V | I2C, SPI UART | 0 ~ +70C | TQFP-80 | |
| AX88772LF | High (2.0) | - | 10/100 | MII | - | - | V | - | 0 ~ +70C | LQFP-128 |
